Stainless Steel Woven Mesh
Product Description
Stainless steel Woven Mesh is selected for their wear-resisting, heat-resisting, acid-resistant and corrosion resisting characteristics. The wire mesh made of stainless steel woven mesh is extensively used in mining, chemical industry, food industry and pharmaceutical industry.
Material:
201, 202, 304, 304L, 316, 316L, 308L, 321, Duplex 2205, 2207, 2900, 2304
Weaving Pattern:
Plain, Crimped, Dutch, Twill
Properties:
Acid resisting, Alkali and Heat resisting
Application:
Sifting and filtering in acid and alkali conditions. Slurry net in petroleum, sifting and screening mesh in chemical and chemical fiber industry, acid washing mesh in electroplating industry.
Quick Links
Blogs
Product Specification Chart
| Stainless Steel Woven Mesh | |||||
|---|---|---|---|---|---|
|
Weaving Techniques |
Plain, Crimped, Dutch, Twill |
||||
|
Available Materials |
201, 202, 304, 304L, 316, 316L, 308L, 321, Duplex 2205, 2207, 2900, 2304 |
||||
|
Mesh per Inch |
Wire Diameter |
Aperture |
Open Area % |
||
|
Inch |
MM |
Inch |
MM |
||
|
1 x 1 |
0.11 |
3.0 |
0.88 |
22.4 |
77.80 |
|
2 x 2 |
0.059 |
1.5 |
0.44 |
11.2 |
77.70 |
|
2 x 2 |
0.047 |
1.2 |
0.45 |
11.5 |
82.00 |
|
3 x 3 |
0.054 |
1.37 |
0.279 |
7.09 |
70.10 |
|
4 x 4 |
0.031 |
0.8 |
0.218 |
5.55 |
76.00 |
|
4 x 4 |
0.047 |
1.2 |
0.203 |
5.15 |
65.80 |
|
5 x 5 |
0.039 |
1.0 |
0.159 |
4.08 |
64.50 |
|
5 x 5 |
0.047 |
1.2 |
0.152 |
3.88 |
58.30 |
|
6 x 6 |
0.025 |
0.65 |
0.141 |
3.58 |
71.60 |
|
6 x 6 |
0.039 |
1.0 |
0.127 |
3.23 |
58.20 |
|
8 x 8 |
0.027 |
0.7 |
0.097 |
2.47 |
61.00 |
|
8 x 8 |
0.047 |
1.2 |
0.077 |
1.97 |
38.00 |
|
10 x 10 |
0.018 |
0.46 |
0.081 |
2.08 |
67.00 |
|
10 x 10 |
0.019 |
0.50 |
0.08 |
2.04 |
64.00 |
|
12 x 12 |
0.013 |
0.35 |
0.069 |
1.76 |
69.00 |
|
12 x 12 |
0.015 |
0.40 |
0.067 |
1.71 |
65.00 |
|
14 x 14 |
0.013 |
0.35 |
0.057 |
1.46 |
65.00 |
|
14 x 14 |
0.015 |
0.40 |
0.055 |
1.41 |
60.00 |
|
16 x 16 |
0.013 |
0.35 |
0.048 |
1.23 |
60.00 |
|
16 x 16 |
0.015 |
0.40 |
0.046 |
1.18 |
55.00 |
|
18 x 18 |
0.011 |
0.30 |
0.043 |
1.11 |
62.00 |
|
20 x 20 |
0.019 |
0.50 |
0.03 |
0.77 |
37.00 |
|
20 x 20 |
0.016 |
0.40 |
0.034 |
0.86 |
46.00 |
|
20 x 20 |
0.01 |
0.27 |
0.039 |
1.00 |
62.00 |
|
24 x 24 |
0.014 |
0.35 |
0.0277 |
0.7 |
44.20 |
|
30 x 30 |
0.012 |
0.30 |
0.0213 |
0.54 |
40.80 |
|
30 x 30 |
0.007 |
0.18 |
0.0262 |
0.66 |
60.80 |
|
35 x 35 |
0.011 |
0.28 |
0.0176 |
0.45 |
37.90 |
|
40 x 40 |
0.014 |
0.25 |
0.015 |
0.38 |
36.00 |
|
40 x 40 |
0.007 |
0.18 |
0.017 |
0.45 |
50.00 |
|
50 x 50 |
0.005 |
0.15 |
0.013 |
0.35 |
47.00 |
|
60 x 60 |
0.005 |
0.15 |
0.01 |
0.27 |
40.70 |
|
70 x 70 |
0.0055 |
0.14 |
0.0087 |
0.22 |
37.00 |
|
80 x 80 |
0.0047 |
0.12 |
0.0077 |
0.197 |
38.80 |
|
90 x 90 |
0.0047 |
0.12 |
0.0061 |
0.16 |
30.00 |
|
100 x 100 |
0.10 |
0.0060 |
0.0060 |
0.15 |
34.80 |
| Stainless Steel Woven Mesh | |||||
|---|---|---|---|---|---|
|
Weaving Techniques |
Plain, Crimped, Dutch, Twill |
||||
|
Available Materials |
201, 202, 304, 304L, 316, 316L, 308L, 321, Duplex 2205, 2207, 2900, 2304 |
||||
|
Mesh per Inch |
Wire Diameter |
Aperture |
Open Area % |
||
|
Inch |
MM |
Inch |
MM |
||
|
120 x 120 |
0.0031 |
0.08 |
0.0051 |
0.1316 |
38.80 |
|
140 x 140 |
0.0027 |
0.07 |
0.0043 |
0.1114 |
37.80 |
|
160 x 160 |
0.0025 |
0.06 |
0.0038 |
0.0965 |
36.40 |
|
180 x 180 |
0.0023 |
0.05 |
0.0033 |
0.0838 |
34.70 |
|
200 x 200 |
0.0019 |
0.05 |
0.003 |
0.077 |
37.00 |
|
250 x 250 |
0.0016 |
0.0406 |
0.0024 |
0.061 |
36.00 |
|
270 x 270 |
0.0016 |
0.0406 |
0.0021 |
0.0533 |
32.20 |
|
300 x 300 |
0.0051 |
0.0381 |
0.0018 |
0.0457 |
29.70 |
|
325 x 325 |
0.0014 |
0.0356 |
0.0017 |
0.0432 |
30.00 |
|
400 x 400 |
0.001 |
0.0254 |
0.0015 |
0.37 |
36.00 |
|
500 x 500 |
0.001 |
0.0254 |
0.001 |
0.0254 |
25.00 |
|
635 x 635 |
0.0008 |
0.0203 |
0.0008 |
0.0230 |
25.00 |
